Network
Technology : GSM / CDMA / HSPA / EVDO / LTE / 5G
Launch
Announced : 2020, September 13
Status : Available. Released 2020, November 13
Body
Dimensions : 160.8 x 78.1 x 7.4 mm (6.33 x 3.07 x 0.29 in)
Weight : 228 g (8.04 oz)
Build : Glass front, glass back, stainless steel frame
SIM : Nano-SIM + eSIM
IP68 dust tight and water resistant (immersible up to 6m for 30 min)
Apple Pay (Visa, MasterCard, AMEX certified)
Display
Type : Super Retina XDR OLED, HDR10, Dolby Vision, 800 nits (HBM), 1200 nits (peak)
Size : 6.7 inches, 109.8 cm2 (~87.4% screen-to-body ratio)
Resolution : 1284 x 2778 pixels, 19.5:9 ratio (~458 ppi density)
Protection : Ceramic Shield glass
Platform
OS : iOS 14.1, upgradable to iOS 18.6
Chipset : Apple A14 Bionic (5 nm)
CPU : Hexa-core (2x3.1 GHz Firestorm + 4x1.8 GHz Icestorm)
GPU : Apple GPU (4-core graphics)
Memory
Card slot : No
Internal : 128GB 6GB RAM, 256GB 6GB RAM, 512GB 6GB RAM, 1TB 6GB RAM NVMe
Main Camera
Triple : 12 MP, f/1.6, 26mm (wide), 1/1.9", 1.7µm, dual pixel PDAF, sensor-shift OIS
12 MP, f/2.2, 65mm (telephoto), 1/3.4", 1.0µm, PDAF, OIS, 2.5x optical zoom
12 MP, f/2.4, 13mm, 120˚ (ultrawide), 1/3.4", 1.0µm
TOF 3D LiDAR scanner (depth)
Features : Dual-LED dual-tone flash, HDR (photo/panorama)
Video : 4K@24/25/30/60fps, 1080p@25/30/60/120/240fps, 10‑bit HDR, Dolby Vision HDR (up to 60fps), stereo sound rec.
Selfie Camera
Single : 12 MP, f/2.2, 23mm (wide), 1/3.6", 1.0µm
SL 3D, (depth/biometrics sensor)
Features : HDR
Video : 4K@24/25/30/60fps, 1080p@25/30/60/120fps, gyro-EIS
Sound
Loudspeaker : Yes, with stereo speakers
3.5mm jack : No
Comms
WLAN : Wi-Fi 802.11 a/b/g/n/ac/6e, tri-band, hotspot
Bluetooth : 5.0, A2DP, LE
Positioning : GPS, GLONASS, GALILEO, QZSS
NFC : Yes
Radio : No
USB : Lightning, USB 2.0
Features
Sensors : Face ID, accelerometer, gyro, proximity, compass, barometer Ultra Wideband (UWB) support
Battery
Type : Li-Ion 3687 mAh (14.13 Wh)
Charging : Wired, PD2.0, 50% in 30 min
15W wireless (MagSafe)
15W wireless (Qi2) - requires iOS 17.2 update
